| Specification( SIZE) | L | H | d | I |
| 1/2″(DN15) | 140.00 | 194.00 | 20.00 | 21.00 |
| 3/4″(DN20) | 142.00 | 196.00 | 25.00 | 21.00 |
| 1″(DN25) | 176.00 | 262.00 | 32.00 | 26.00 |
| 1-1/4″(DN32) | 180.00 | 272.00 | 40.00 | 28.50 |
| 1-1/2″(DN40) | 245.00 | 380.00 | 50.00 | 37.00 |
| 2″(DN60) | 258.00 | 390.00 | 63.00 | 37.00 |
| 2-1/2″(DN65) | 343.00 | 394.00 | 75.00 | 42.00 |
| 3″(DN80) | 365.00 | 406.00 | 90.00 | 50.00 |
| 4″DN100) | 568.00 | 487.00 | 110.00 | 60.00 |
